TDO-510D
Depending on the wood species and moisture content, the machine is capable of grinding branches up to 8 cm in diameter. The final output serves as high-quality raw material for solid fuel and pyrolysis boilers, fireplaces, stoves, and various other heating appliances. Additionally, the processed wood chips can be utilized effectively as organic mulch or nutrient-rich fertilizer for agricultural and landscaping purposes.
Max. 8 cm
Min. Required Tractor Power: 24 HP
Number of Blades: 3 Resharpenable Blades.
2 Years
Technical Specifications
Key data shaping your machine's performance
| Feature | Value |
|---|---|
| Model | TDO-510D |
| Dimensions (W x L x H) | 105 x 168 x 121 cm |
| Weight | 260 Kg |
| Circular Saw Feature | 400 mm Diamond-Tipped Blade |
| Feeding | Gravity-Fed Self-Feeding System |
| Infeed Hopper | (H)53 / (W)70 cm |
| Discharge System | Side Discharge System |
| Transport System | 3 Point Hitch System |
| Warranty Period | 2 Year Official Warranty |
Required Power: Min. 24 HP (Tractor PTO)
Grinding Capacity: 8 cm (80 mm)
Number of Blades: 3 Resharpenable Blades.
Feeding System: Gravity-Fed / Self-Feeding for Effortless Operation.
Circular Saw: 400 mm Diamond-Tipped (TCT) Blade.
- Double the functionality, double the efficiency with the Aydınmaksan TDO-510D!
- The TDO-510D is a high-performance, multi-functional powerhouse designed for tractors of 24 HP and above. What sets this model apart is its dual-action capability: it features precision-engineered, resharpenable Swedish steel blades for chipping and a 400 mm diamond-tipped (TCT) circular saw for cutting logs. This hybrid design allows you to process branches up to 8 cm in diameter and cut thick timber into stove-ready firewood with a single machine.
- With a high-yield capacity of 1–1.5 tons per hour, the TDO-510D is the ultimate solution for agricultural waste management. Whether you are producing solid fuel for fireplaces and boilers or nutrient-rich compost for your soil, this machine transforms nature’s waste into valuable resources. The 3-point hitch (T-connection) ensures effortless attachment and secure transport across all terrains.
- Built for longevity, the blades undergo a specialized induction heat treatment for maximum wear resistance. The entire chassis is finished with industrial grinding and premium powder coating to withstand the harshest outdoor conditions. Proudly 100% locally manufactured and backed by a 2-year warranty, the TDO-510D comes with Aydınmaksan’s signature after-sales support and quality assurance.
