TDO-700M
The machine is specifically engineered to process high-moisture organic waste, such as banana stems, palm leaves, and various saplings, transforming them into uniform wood chips. Once processed, these botanical wastes can be fermented for 3 to 4 months, resulting in a nutrient-rich organic layer ready to be spread across the soil surface.
Max. Processing Diameter: 90 mm (Timber) / 260 mm (Fibrous/Soft Material).
Min. Required Tractor Power: 35 HP
3 Resharpenable Blades
2 Years
Technical Specifications
Key data shaping your machine's performance
| Feature | Value |
|---|---|
| Model | TDO-700M |
| Dimensions (W x L x H) | 106 x 137 x 140 cm |
| Weight | 350 Kg |
| Feeding | Self-Feeding Gravity Intake |
| Hopper Width | (H)53 / (W)70 cm |
| Discharge System | Side Discharge System |
| Transport System | 3-Point Hitch System |
| Warranty Period | 2 Year Official Warranty |
Power Source: Min. 35 HP Tractor Power
Operating Capacity: 9 cm Chipping Capacity (Up to 26 cm for Banana, Palm, etc.)
Number of Blades: 3 Resharpenable Blades
Feeding System: Self-Feeding Gravity Intake for Easy Operation.
- The TDO-700M is a professional-grade wood chipper designed for seamless integration with tractors of 35 HP and above. Engineered for versatility, it features a dual-capacity system: processing standard woody branches up to 9 cm and high-moisture, fibrous materials like banana and palm stems up to 26 cm. This unique design ensures that water-dense botanical waste is discharged effortlessly without clogging, making it a reliable partner for tropical agriculture and diverse plantations.
- Our commitment to durability is reflected in the cutting system, which utilizes premium Swedish steel blades. Each blade undergoes a rigorous high-frequency induction heat-treatment process in our own facilities to ensure maximum longevity and sharpness. The TDO-700M delivers a consistent output of 1–1.5 tons per hour, producing high-quality wood chips ideal for solid fuel boilers, fireplaces, or nutrient-rich organic compost. By returning natural waste back to the soil, it promotes a circular, eco-friendly farming cycle.
- Manufactured 100% in-house, every TDO-700M undergoes strict quality control, including precision grinding of all mounting surfaces and ultrasonic testing of welded joints. Finished with a heavy-duty powder coating for superior corrosion resistance, this model is built for the toughest environments. Backed by a 24-month warranty and comprehensive after-sales support, the TDO-700M is your trusted assistant on the path to energy independence and efficient waste management.
